| Product number |
FCB-EV7520A |
| Image Sensor |
1/2.8 inch Exmor R CMOS |
| Image sensor (effective number of pixels) |
About 2.13 million pixels |
| signal system |
1080p/59.94, 1080p/50, 1080p/29.97, 1080p/25, 1080i/59.94, 1080i/50, |
| 720p/59.94, 720p/50, 720p/29.97, 720p/25, NTSC*1, PAL*1 |
| Minimum illumination (50%) |
High sensitivity mode |
Color : 0.01 lx (F1.6, automatic gain control on, 1/30 second) |
| Normal mode |
Color : 0.1 lx (F1.6, automatic gain control on, 1/30 second) |
| Recommended illumination |
100 lx to 100,000 lx |
| Signal to noise ratio |
More than 50 dB |
| Gain |
Auto/Manual (0 steps to 28 steps, +2 steps / total 15 steps)
Maximum gain limit (6 steps to 28 steps, +2 steps / total 12 steps) |
| Shutter speed |
1/1 second to 1/10,000 second, 22 steps |
| Synchronization system |
Built in |
| Exposure control |
Auto, Manual, Priority Mode (Shutter Priority & Aperture Priority), Brightness, EV Compensation, Slow AE |
| BLC |
Have |
| Pitch control |
16 steps |
| White balance |
Auto, Auto Tracking White Balance, Indoor, Outdoor, Outdoor Auto, Sodium (Fixed / Auto / Outdoor) , One-Touch, Manual |
| Lens |
30x optical zoom |
| f=4.3mm (wide-angle end) to 129.0mm (distal) |
| F1.6 to F4.7 |
| Digital zoom |
12 times (360 times after using optical zoom) |
| Focusing system |
Auto (sensitivity: normal, low), one-button auto focus, manual, interval auto focus, zoom trigger auto focus, focus compensation when ICR mode is on |
| Viewing angle (horizontal) |
1080p mode |
63.7° (wide-angle end) to 2.3° (distal) |
| 720p mode |
63.7° (wide-angle end) to 2.3° (distal) |
| SD mode |
47.8° (wide-angle end) to 1.7° (distal) |
| Minimum object distance |
10 mm (wide end) to 1200 mm (distal) (default: 300 mm) |
| Automatic ICR |
Have |
| Wide-D *2 |
no |
| Visual enhancement |
Have |
| Noise reduction |
Yes (6 steps) |
| Progressive scan mode |
Have |
| Image stabilizer |
Have |
| StableZoom |
Have |
| Digital output interface |
Have |
| Spherical privacy zone shadowing |
Have |
| Motion detection |
Have |
| Alarm function |
no |
| Slow AE response |
Have |
| Image effects |
Electronic flip, negative, black and white, mirroring, color enhancement |
| Image freeze |
Have |
| Slow shutter |
Have |
| Temperature reading |
Have |
| Title display |
20 characters / line, up to 11 lines |
| Camera component mode display |
Have |
| Button switching control |
no |
| Camera component operation switching |
no |
| Video output |
HD |
Analog: N/A number: Y/Cb/Cr 4:2:2, using LVDS (signal format conforms to SMPTE 274/SMPTE 296.) |
| SD |
VBS |
| Camera component control interface |
VISCA (CMOS 5 V class)
baud rate: 9.6 Kbps, 19.2 Kbps, 38.4 Kbps, 115.2 Kbps, stop bit: 1 bit |
| Power requirement |
6.0 V to 12.0 V DC |
| Power consumption |
Power consumption 3.2 W (zoom/focus does not start) 4.0 W (zoom/focus start) |
| Operating temperature |
-5°C to 60°C |
| Storage temperature |
-20 ° C to 60 ° C |
| Operating humidity |
20% to 80% |
| Storage humidity |
20% to 95% |
| Size (width × height × depth) |
50.0×60.0×89.7 mm |
| weight |
255 g |
Sony FCB camera block
Functionally: FCB-EV7520A has anti-shake function, while FCB-EV7320 does not.
FCB-EV7520A is 255g, while FCB-EV7320 is 256g
PS: The difference between and Sony HD movement FCB-EV7500 and FCB-EV7520 parameters difference
In order to meet the demand for high-quality, high-resolution images that the full HD format can provide , Sony has introduced a series of new HD camera components FCB-EV series.
Capturing the sharp, clear Full HD (1080/60p) image quality, the
is ideal for shooting.
Fast response, highlens
uses an image stabilizer, optical and digital zoom to improve picture quality while maintaining the original horizontal viewing angle to ensure that the picture size remains the same and reduces blurring.
features advanced noise reduction technology that filters out unwanted noise in the picture, giving users a clear picture even in low-light environments. The noise reduction level can be selected from five levels to accommodate a variety of different operating environments.
picture quality can be dynamically enhanced. In a given dynamic range, the picture is continuously adjusted to adjust the scene pixel by pixel. In addition, they also have a fog-passing function that instantly captures sharper images in a smoky environment.
The fog-
HLC ( Highlight Compensation )
Automatic ICR ( Automatic IR Cut Filter Removal )A wide range of versatile operations
operationE-Flip, Nega art, black and white, mirroring, color enhancementProviding clear monitoring images
Automatic day/night conversion functionThe spherical privacy zone masks theThe shaded area is automatically locked as the camera pans/tilts/zooms.
