VRS-HD4110 is a 10x high-definition network camera module, specifically designed for the security surveillance and drone fields. Excellent Performance: VRS-HD4110 boasts starlight-level ultra-low illuminance performance,enabling clear imaging even in dim light. Motion detection can sensitively capture dynamics. Automatic IR-cut filter switching adapts to daylight and nighttime illumination changes. 3D digital noise reduction and code stream technology optimize image quality and reduce transmission pressure. Flexible Configuration: VRS-HD4110 supports independent setting of resolution and frame rate to adapt to diverse scenarios. Large-capacity Micro SD/SDHC/SDXC card storage meets local data storage requirements. It adheres to ONVIF and GB/T28181 standards for access, featuring strong compatibility, rich interfaces, and ease of integration. Compact and Easy to Use: With a compact and low-power design, VRS-HD4110 can be easily integrated into indoor and outdoor dome cameras, pan-tilt devices, etc. Leveraging its high performance, multi-functionality, and ease of integration, VRS-HD4110 becomes an ideal choice in the security surveillance and drone fields.Features
• The maximum resolution can reach 4 mega pixels ( 2560 * 1440 ), and the maximum output of full HD 2560 × 1440 @30fps real-time images. • Support H.265/H.264 video compression algorithm, support multi-level video quality configuration and coding complexity setting. • Starlight level ultra-low illumination, 0.0 01 Lux/F1.7 (color), 0.0 005 Lux/F1.7 (black and white), 0 Lux with IR. • Supports 10x optical zoom and 16x digital zoom. • Support basic detection functions such as motion detection. • Supports three-stream technology, each stream can be independently configured with resolution and frame rate. • ICR infrared filter type automatic switching to achieve true day and night monitoring. • Supports backlight compensation, automatic electronic shutter and other functions to adapt to different monitoring environments. • Supports 3D digital noise reduction, strong light suppression , 120dB optical wide dynamic range. • Supports 255 preset positions and 8 cruise scans. • Supports scheduled snapshot and event snapshot functions. • Supports one-key watch and one-key cruise functions. • Support 1 audio input and 1 audio output. • Built-in 1 alarm input and 1 alarm output, supporting alarm linkage function. • Supports Micro SD/SDHC/SDXC card storage up to 256G. • Support ONVIF, GB/T28181 access. • Rich interfaces for easy function expansion. • Small size, low power consumption, easy to connect to dome cameras and gimbals.Product Specs
Volers VRS-HD4110 IP Camera Block Product Specs
| Camera parameters | |
| Model | VRS-HD4110 |
| Image Sensor | 1/2.8" CMOS Sensor |
| Scanning system | Progressive Scan |
| Sync. System | Internal |
| Minimum illumination | Color : 0.0 0 1 Lux @ (F1.7, AGC ON); Black and white : 0.00 05 Lux @ (F1.7, AGC ON) |
| Electronic | 1/25 sec to 1/100,000 sec; supports slow shutter |
| Auto iris | DC drive |
| Electronic | 1/25 sec to 1/100,000 sec; supports slow shutter |
| Day and night | Automatic ICR infrared filter type |
| Lens parameters | |
| Lens type | 10x Day & Night Zoom Lens |
| Zoom Ratio | Optical 10x, Digital 16x Zoom |
| Focal Length | f = 4.8mm ~ 48mm |
| Aperture Ratio | F1.7 (wide) ~ F3.1 (tele) |
| Horizontal | 62-7.6 degrees (wide angle-telephoto) |
| Close range | 1000mm-2000mm (Wide angle-telephoto) |
| Zoom speed | About 3.5 seconds (optical, wide-angle-telephoto) |
| Compression standard | |
| Video | H.265/H.264 |
| H.265 encoding | Main Profile |
| H.264 encoding | BaseLine Profile / Main Profile / High Profile |
| Video | 32Kbps~16Mbps |
| Audio | G.711a/G.711u/G.722.1/G.726/MP2L2/AAC/PCM |
| Audio compression bit | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/16-64Kbps(AAC) |
| Image parameters ( maximum image size: 2560*1440 ) | |
| Main stream resolution | 50Hz: 25fps (2560*1440 , 1920 × 1080, 1280 × 720); 60Hz: 30fps (2560*1440 , 1920 × 1080, 1280 × 720) |
| Third stream resolution and frame rate | Independent of the main stream setting, the highest supported: 50Hz: 25fps ( 704 * 576 ); 60Hz: 30fps ( 704 * 576 ) |
| Image settings | Saturation , brightness , contrast , and sharpness are adjustable through the client or browser |
| BLC | Support , customizable area |
| Exposure mode | Auto exposure/aperture priority/shutter priority/manual |
| Focus mode | Auto focus/one time focus/manual focus/semi-automatic focus |
| Area | support |
| Through fog | support |
| Day and night | Automatic , manual , timing , alarm trigger |
| 3D noise | support |
| Picture overlay | Support BMP 24 -bit image overlay , customizable area |
| Area of | ROI supports setting 4 fixed areas for three streams respectively |
| Internet function | |
| Storage function | Supports Micro SD/SDHC/SDXC card ( 256 G) offline local storage , NAS (NFS, SMB/CIFS are supported |
| Supporting | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, RTP, RTSP, RTCP, NTP, SMTP, SNMP, IPv6 |
| Interface Protocol | ONVIF (PROFILE S, PROFILE G), GB28181-2016, domestic mainstream manufacturer agreement |
| Interface parameters | |
| External Interface | 36pin FFC ( including network port, RS485 , RS232 , SDHC , Alarm In/Out , Line In/Out , power supply ) |
| General specifications | |
| Operating | -30 ℃ ~ 60 ℃ , humidity less than 95% ( no condensation ) |
| Power supply | DC12V± 10 % |
| Power | 2.5W static ( 4W MAX) |
| Working current | 120 mA |
| Size | 62.7*50.8*43.8mm (shell solution), 61.7*42.4*50.3 (bracket solution) |
| Weight | 160g (shell solution), 100g (bracket solution) |
