SDI video signal splitter real-time HD digital signal 1080p@60Hz full HD output

VRS-DS104 high-definition SDI video signal splitter can distribute any high-definition serial digital video signal into four high-definition HD-SDI with high definition, no distortion and no delay. 3G-SDI serial digital video signal. In the high-definition security monitoring system, a high-definition HD-SDI video signal can be assigned to high-definition monitor, high-definition hard disk recorder, high-definition matrix, high-definition network video server for synchronous use. And the image without distortion, no delay, no compression, real real-time high-definition digital signal. And achieve perfect 1080p@60Hz full HD output.

SDI video signal splitter Key Features:

Support 1 channel SDI signal input, 4 channels high fidelity, no loss SDI signal output

Supports SDI; HD SDI; 3G-SDI video signal input and output. Support rates 270Mbps -- 2.97Gbps

HD-SDI video splitters use all-digital, non-compression technology

Supports standard definition SDI (270Mbps), HD HD-SDI (1.485Gbps), and full HD 3G-SDI (2.97Gbps) video formats

No software Settings are required, and hot swap and plug and play functions are supported

Built-in protection against lightning shock and power surge, stable and reliable communication quality

Use full industrial grade wide temperature range design, industrial grade chip, full surface mount technology

HD-SDI video splitter adopts advanced switching power supply, excellent performance, high temperature, cold resistance, can effectively prevent electromagnetic radiation interference

Maximum cable length (Belden-B1694) : SD support 400m, HD support 200m, 3G support 140m

Excellent SDI signal jitter suppression function, close to perfect eye map index
