| Image Sensor
(# Of Effective Pixels) |
1/2.5-type Exmor R CMOS Sensor (8510K pixels) |
| Output Pixels (H × V) |
3840x2160 (QFHD), 1920x1080 (Full HD), 1280x720 (HD), 720x480/576 (SD) |
| Signal System |
2160p/29.97, 2160p/25, 2160p/23.98, 1080p/59.94, 1080p/50, 1080p/29.97, 1080p/25, 1080p/23.98, 1080i/59.94, 1080i/50, 720p/59.94, 720p/50, 480p/59.94, 576p/50 |
| Minimum Illumination (50%, High Sensitivity Mode) |
0.4 lx (Shutter Speed : 1/30 s)
0.06 lx (Shutter Speed : 1/4 s or 1/3 s) |
| Recommended Illumination |
100 lx to 100,000 lx |
| SNR |
50 dB |
| Gain |
Auto / Manual (0 dB to 48.0 dB), 0 to 16 steps |
| Shutter Speed |
1 / 1 to 1 / 10000 s, 22 steps |
| Sync System |
Internal / External |
| Exposure Control |
0 dB to ± 10.5 dB, 15 steps |
| Backlight Compensation |
Yes |
| Gamma |
Standard / Straight gamma |
| Aperture Control |
16 steps |
| White Balance |
Auto, ATW, Indoor, Outdoor, One Push WB, Manual WB, Outdoor Auto, Sodium Vapor Lamp (Fix/Auto/Outdoor Auto) |
| AE (Auto Exposure Mode) |
Full Auto, Manual, Priority mode (shutter/iris), Bright, EV Compensation |
| Lens (wide to tele) |
20x optical zoom,
f = 4.4 mm to 88.4 mm, F2.0 to F3.8 |
| Zoom Mode |
Standard Mode / Variable Mode / Direct Mode |
| Super Resolution Zoom |
QFHD : 1.5x (max. 30x with optical zoom)
Full HD/HD : 2.0x (max. 40x with optical zoom) |
| Digital Zoom |
12x (240x with optical zoom) |
| Optical wide to Optical tele |
3.0 s (Focus Tracking ON) |
| Optical wide to Super resolution zoom tele |
3.4 s |
| Optical wide to Digital zoom tele |
5.0 s |
| Focusing System |
Auto Focus (Normal AF, Interval AF, Zoom Trigger AF [Sensitivity : normal, low]), Manual (Standard, Variable, Direct), One Push Trigger, Near Limit, Spot Focus, IR Correction |
| Focus Movement time |
∞ to Near : 0.1 s |
| Horizontal Viewing Angle (QFHD/Full HD/HD) (wide end to tele end) |
Approx. 70.2° to 4.1° (Image stabilizer OFF)
Approx. 60.0° to 3.5° (Image stabilizer ON) |
| Minimum Object Distance (wide end to tele end) |
80 mm to 800 mm |
| Auto ICR |
Yes |
| Wide Dinamic Range (Wide-D) |
- |
| (Auto mode) |
- |
| Visibility Enhancer |
Yes |
| Defog |
Yes (low / mid / high) |
| Noise Reduction |
Yes (3D+2D, Independent setting (3D, 2D)) |
| Image Stabilization |
Yes |
| StableZoom |
Yes |
| Digital Output |
Yes |
| Spherical Privacy Zone Masking |
Yes |
| Motion Detection |
- |
| Alarm (Auto ICR) |
Yes |
| Slow AE Response |
Yes |
| Picture Effects |
Black & White (Monochrome Image) |
| Picture Freeze |
Yes |
| Electronic-Flip (E-FLIP) |
Yes |
| Mirror Image |
Yes |
| Slow Shutter |
Yes |
| Temperature Readout |
Yes |
| Title Display |
Yes |
| Date/Time Display |
- |
| Camera Mode Display |
Yes (English) |
| Key Switch Control |
- |
| Camera Operation Switch |
- |
| Video Output (QFHD/Full HD/SD) |
Digital : Y/Cb/Cr 4:2:2 8 bits component, R/G/B 4:4:4 8 bits component, Comparable to CEA-861-F *2 |
| Camera Control Interface |
VISCA protocol (CMOS 3.1V) PTP USB 9.6 kbps, 19.2 kbps,38.4 kbps, 115.2 kbps, Stop bit : 1 bit |
| Power Requirements |
6.0 V to 12.0 V DC |
| Power Consumption |
3.0 W (When the motor operates : 4.0 W) |
| Operating Temperature |
-5 °C to +60 °C (23 °F to 140 °F) |
| Storage Temperature |
-20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity |
20% to 80% (Absolute humidity : 36 g/m3) |
| Storage Humidity |
20% to 95% (Absolute humidity : 36 g/m3) |
| Dimensions (W x H x D) |
50.0 × 60.0 × 93.3 mm (2 × 2 3/8 × 3 3/4 in.) |
| Mass |
Approx. 275 g (10 oz.) |
Sony FCB camera block
